Blackmagic PYXIS 12K

Name: Blackmagic PYXIS 12K
Brand: Blackmagic
SKU: PRE-95011
Price: 12498.75 USD
Availability: InStock

SKU PRE-95011

Save 7%

$13,498.65

$13,498.65 - $13,498.65

$13,498.65

$12,498.75

$12,498.75 - $12,498.75

$12,498.75

Status: Pre‑Order
ETA: TBD
Reserve yours now.

This product can be cancelled anytime prior to shipment.

Business Financing Options Available.

Key Features

Large-Format Full-Frame 12K Sensor
16 Stops of Dynamic Range
Blackmagic RAW up to 12K 3:2 Open Gate
Built-In Optical Low-Pass Filter
Two CFexpress Card Slots, USB-C Port
Compact Form with Switchable Side Plates
4" HDR LCD Touchscreen
10GbE Ethernet Port, 10GHDBase-T Support
HFR Button & Three Assignable Shortcuts
Mini-XLR & 3.5mm Audio Inputs

Mobile App Compatible

Yes: Android & iOS

Quantity

Our Customers & Partners

Features

Easy-to-Rig 12K Full-Frame Camera

The Blackmagic Design PYXIS 12K Cinema Box Camera combines a full-frame 12K RGBW sensor that captures rich colors and accurate skin tones with the compact, versatile design of the PYXIS 6K camera. It features a native, active Leica L lens mount, a 36 x 24mm sensor, a wide 16-stop dynamic range, and customizable side plates.

Large-Format Digital Film Sensor

The PYXIS 12K's massive 24 x 36mm full-frame RGBW sensor boasts a native 12,288 x 8040 resolution, letting you create shallow depth of field or use anamorphic lenses without cropping for a truly cinematic look. A 16-stop dynamic range with dual-native ISO up to 25,600 ensures low-noise imagery in all lighting conditions.

Flexible Film Formats

Work in a variety of film formats and aspect ratios without sacrificing quality, thanks to the large sensor. You can also work in true 6:5 anamorphic without needing to crop for widescreen cinematics. Use a Super 35-sized window to create an instant close-up version of your open-gate shot.

Multiple Resolutions and Frame Rates

Shoot in standard video resolutions and frame rates from HD to 12K using the PYXIS 12K with the ability to capture in 12K, 8K, or 4K at the full sensor size. Available resolutions include up to 40 fps at 12,288 x 8040 3:2 open gate, 60 fps at 12,288 x 5112 2.4:1, and 112 fps at 8192 x 3408 8K. There's even an HFR (high framerate) button for quickly switching to your rate without having to access the menu.

HDR Imagery and Dual-Native ISO

The wide 16-stop dynamic range preserves more detail in both the lightest and darkest areas of your image. Set the exposure for an indoor scene while retaining details in the bright outdoor light coming through a window. Optimized for ISO 800, the PYXIS 12K offers ISOs of 200 to 3200 and a maximum ISO 25,600, minimizing grain and noise in your images while maintaining the full dynamic range of the sensor.

Optional Pro Handle and Pro Grip

Use the new Pro Handle and/or Pro Grip to transform your PYXIS 12K into an ENG-style camera for fast, run-and-gun capture. The Pro Handle features an OLED, daylight-visible HD viewfinder, a zoom rocker with recording run/stop, and a stereo microphone. The Pro Grip also provides a zoom rocker with run/stop plus a handgrip for secure handheld capture.

Customizable Rigging

Crafted from lightweight yet robust aerospace-grade aluminum, the easy-to-rig PYXIS 12K features multiple 1/4"-20 and 3/8"-16 threads for mounting it on a gimbal, crane, or drone. It also has a range of side plates designed for attaching handgrips, SSD recorders, microphones, and more. It includes a side plate with one 3/8"-16 and two 1/4"-20 threads and an SSD plate with an optional rosette plate with additional threads available separately.

LCD Monitor and Onboard Controls

Use the built-in 4" LCD touchscreen to monitor and review your shots on set. This full HD-resolution, HDR-compatible screen lets you frame and focus without requiring an additional external unit. A maximum brightness of 1500 cd/m² ensures visibility even in bright sunlit conditions. On-screen overlays show status and recording parameters, histograms, levels, frame guides, and 3D LUTS, among other tools.
Onboard controls allow you to toggle functions like ISO, white balance, and shutter with ease. A scroll wheel makes quick adjustments, and three customizable function buttons can tailor your workflow to your preference. The controls can be locked to avoid accidental pressing during shooting.

Post-Production-Friendly Formats

The PYXIS 12K records in Blackmagic RAW, preserving detail, exposure, and color control during post-production. It can also record H.264 proxy files in real time for easy sharing. Blackmagic RAW works with Apple Metal, CUDA, and OpenCL, and its media files work on all operating systems.

Multiple Recording Options

Two built-in CFExpress Type-B card slots and a USB-C expansion port allow you to record directly to external flash media disks or SSDs. The high speed of CFexpress cards lets you capture an hour plus in 6K on a single 256GB card.

Live Syncing to Blackmagic Cloud

News and live event content creators will appreciate the ability to shoot and edit in near real-time using Blackmagic Cloud and the PYXIS 12K's proxy files.
Users anywhere in the world can upload proxy footage and have their editors start working on scenes almost instantly.

Built-In Streaming

Live stream directly from the PYXIS 12K on set to a secondary location via SRT and RTMP protocols. Compatible platforms like YouTube, Facebook, and X can support signals from the PYXIS 12K for live event production. To share content internally, use an ATEM Streaming Bridge for a wireless link back to the studio.

Expansive Connectivity

The front of the PYXIS 12K boasts a USB-C port for the Blackmagic URSA Cine EVF and a mini 3-pin XLR analog audio input with +48V Phantom power for microphone integration.
The back of the PYXIS 12K has a headphone monitoring jack and an additional 3.5mm microphone input. Use the USB-C port at the back of the camera to connect to recording devices or mobile data. A 12G-SDI output integrates a secondary monitor.
A Reference/Timecode input port syncs your sources.
Use the fast RJ45 10 GbE Ethernet port supporting up to 10GBase-T to upload footage to Blackmagic Cloud or control the camera remotely.
Power the PYXIS 12K using the locking 2-pin DC power connector or the Sony BP-U battery plate.
Download the Blackmagic Camera Control app for wireless Bluetooth control from up to 30' away.

Item Includes

Blackmagic Design PYXIS 12K Cinema Camera (Leica L)
Len Mount Cap
PYXIS Standard Mounting Plate
PYXIS SSD Mounting Plate
Power Supply with International Adapters (90W)
DaVinci Resolve Studio Activation Key
Limited 1-Year Manufacturer Warranty

Item Includes

Lens Mount	L-Mount
Image Sensor	35.64 x 23.32 mm (Large Format) CMOS
Sensor Resolution	Effective: 98.8 Megapixel (12,288 x 8040)
Image Stabilization	No
Internal Recording	Blackmagic RAW 12288 x 8040 up to 40 fps 9648 x 8040 up to 40 fps 12288 x 6912 up to 45 fps 12288 x 6480 up to 50 fps 7680 x 6408 up to 50 fps 9648 x 6264 up to 50 fps 8192 x 5360 up to 72 fps 6432 x 5360 up to 72 fps 12288 x 5112 up to 60.00 fps 9312 x 4896 up to 65 fps 8688 x 4896 up to 65 fps 8192 x 4608 up to 84 fps 8192 x 4320 up to 90 fps 9312 x 3864 up to 80 fps 8192 x 3408 up to 112 fps 4096 x 2680 3216 x 2680 4096 x 2304 4096 x 2160 4096 x 1704
Video Output	SDI/BNC 4096 x 2160 at 60.00/23.98/50/30.00/24.00/25/59.94/29.97 fps 1920 x 1080p at 60.00/23.98/50/30.00/24.00/25/59.94/29.97 fps
Media/Memory Card Slot	Dual Slot: CFexpress Type B
Video I/O	1x BNC (12G-SDI) Output
Mobile App Compatible	Yes: Android & iOS
Battery Type	Sony BP-U Series

Imaging

Lens Mount	L-Mount
Lens Communication	Yes
Image Sensor	35.64 x 23.32 mm (Large Format) CMOS
Sensor Resolution	Effective: 98.8 Megapixel (12,288 x 8040)
Image Stabilization	No
Capture Type	Stills & Video

Exposure Control

Shutter Type	Electronic Rolling Shutter
Advertised Dynamic Range	16 Stops

Focus

Focus Modes

Automatic, Manual Focus

Video Capture

Internal Recording	Blackmagic RAW 12288 x 8040 up to 40 fps 9648 x 8040 up to 40 fps 12288 x 6912 up to 45 fps 12288 x 6480 up to 50 fps 7680 x 6408 up to 50 fps 9648 x 6264 up to 50 fps 8192 x 5360 up to 72 fps 6432 x 5360 up to 72 fps 12288 x 5112 up to 60.00 fps 9312 x 4896 up to 65 fps 8688 x 4896 up to 65 fps 8192 x 4608 up to 84 fps 8192 x 4320 up to 90 fps 9312 x 3864 up to 80 fps 8192 x 3408 up to 112 fps 4096 x 2680 3216 x 2680 4096 x 2304 4096 x 2160 4096 x 1704
Video Output	SDI/BNC 4096 x 2160 at 60.00/23.98/50/30.00/24.00/25/59.94/29.97 fps 1920 x 1080p at 60.00/23.98/50/30.00/24.00/25/59.94/29.97 fps
Fast-/Slow-Motion Support	No
Built-In Microphone	Stereo

Interface

Media/Memory Card Slot	Dual Slot: CFexpress Type B
Internal Storage	No
Video I/O	1x BNC (12G-SDI) Output
Audio I/O	1x 1/8" / 3.5 mm TRRS Headphone/Mic Headphone Output 1x 1/8" / 3.5 mm TRS Stereo Microphone Input
Power I/O	1x LEMO 2-Pin (12VDC) Input
Other I/O	1x USB-C Viewfinder Output 1x USB-C Video/Data/Control 1x BNC (Reference, Timecode) 1x RJ45 (10 Gigabit Ethernet)
Wireless	Bluetooth
Mobile App Compatible	Yes: Android & iOS
Global Positioning (GPS, GLONASS, etc.)	No

Monitor

Display Type	Primary Monitor: Fixed 4" Touchscreen LCD
Resolution	Primary Monitor: 1920 x 1080

Power

Battery Type

Sony BP-U Series

Environmental

Operating Conditions	32 to 104°F / 0 to 40°C up to90% Humidity
Storage Conditions	-4 to 113°F / -20 to 45°C

General

Tripod Mount	7x 1/4"-20 Female (Bottom) 2x 3/8"-16 Female (Bottom)
Accessory Mounting Thread	2x 1/4"-20 on Camera Body 1x 3/8"-16 on Camera Body 4x M4 on Camera Body
Dimensions (W x H x D)	5.94 x 4.69 x 4.17" / 15.09 x 11.91 x 10.59 cm
Weight	3.5 lb / 1.6 kg (Body Only)
