Features
100% image performance
The G100 series opens up the possibilities of our single-chip offering with higher brightness levels than before. It brings great image quality with an impressive lumens power for bright projections indoor and outdoor. What's more, the G100 supports all the latest input sources, including HDMI 2.0, to ensure deep color palettes and qualitative projections.
Thanks to Barco's Projector Toolset software, installing and managing your projector(s) can be done from the comfort of your own computer with the intuitive user interface. In addition, the Ptoolset blending and warping capabilities make these projectors a perfect fit for multi-channel media-based attractions like planetariums, domes, theatres and projection mappings.
100% flexibility
To enable full operational versatility and effortless implementation in different project designs, this Barco laser projector comes with a stable lens holder to guarantee reliable blending and non-moving images in multi-channel setups, and a new extensive GC-lens range supporting throw ratios from 0.38:1 up to 10.8:1. It gives you flexibility to shoot from long and/or short distances, and to play with 360° orientation possibilities. Barco DLP projectors and their peripherals deliver the best outcomes for any creative project.
With the excellent onboard cooling, the G100s can withstand a maximum ambient operating temperature of 50°C (122°F), at a maximum of only 42 dB noise levels.
100% reliability
Through its laser-phosphor light source and advanced cooling design, the G100 provides a long operating time (>20,000 hours) without need for lamp changes, resulting in considerable cost-savings on maintenance and consumables.
With its up-to-date and future-proof design, the G100 is built to meet all your requirements in terms of image quality, reliability and sustainability.
A-rating ecoscore
The Barco G100-W22 ecoscore is mainly attributable to the overall energy efficiency of the device. With an improved power supply, carefully selected components and low power standby mode, the movie theater projector limits its energy consumption. In addition, the product design and packaging design of this laser phosphor projector are both optimized in terms of weight, which is beneficial for the transport and logistics of the units, positively impacting the eco footprint. Other highlights include the modularity and future-proof upgradeability of the projector, contributing to an extension of the lifetime.
Item Includes
Display System
1-Chip 0.96" DLP
Native Resolution
1920 x 1200
Maximum Brightness
22,000 Lumens (ISO)
20,600 Lumens (Center)
18,500 Lumens (ANSI)
Throw Ratio
0.38 to 10.8:1
HDR Support
No
Inputs/Outputs
2x HDMI 2.0b Audio, Video Input
1x DisplayPort 1.2 Audio, Video Input
1x DVI-D Video Input
1x DE-15/DB-15 (VGA) Video Input
1x RJ45 (HDBaseT) LAN Input/Output
1x RF (3G-SDI) Video Input
Show More
Light Source
Laser Phosphor
Image Display
Display System
1-Chip 0.96" DLP
Native Resolution
1920 x 1200
Supported Resolutions
Maximum: 3840 x 2160 @ 60 Hz
Maximum Brightness
22,000 Lumens (ISO)
20,600 Lumens (Center)
18,500 Lumens (ANSI)
Uniformity
90%
Aspect Ratio
16:10
Contrast Ratio
1100:1
DLP Link 3D
Yes
Lens
Includes Lens
Yes
Lens Shift
Vertical: to 120%
Horizontal: to 50%
Throw Ratio
0.38 to 10.8:1
Features
HDR Support
No
Multi-Input Support (PIP/PBP)
No
Input/Output Connectors
Inputs/Outputs
2x HDMI 2.0b Audio, Video Input
1x DisplayPort 1.2 Audio, Video Input
1x DVI-D Video Input
1x DE-15/DB-15 (VGA) Video Input
1x RJ45 (HDBaseT) LAN Input/Output
1x RF (3G-SDI) Video Input
HDCP Support
Not Specified by Manufacturer
Hardware
Mobile App Compatible
No
Bluetooth
No
General
Light Source
Laser Phosphor
Fan Noise
Full Brightness: 48 dB
Input Power
100 to 240 VAC, 50 / 60 Hz
Power Consumption
Medium Brightness: 1200 W
Full Brightness: 1380 W
Certifications
BIS, BSMI, CCC, CE, EAC, FCC Class A, Kcc, RCM, cTUVus
Operating Conditions
32 to 82°F / 0 to 50°C at 10 to 85% Humidity
Storage Conditions
14 to 140°F / -10 to 60°C at 5 to 90% Humidity
Dimensions (W x H x D)
25.6 x 9.9 x 28.0" / 650.0 x 251.0 x 710.0 mm (Without Feet)
Weight
119 lb / 54 kg
Packaging Info
Package Weight
146 lb
Box Dimensions (LxWxH)
36.88 x 33.5 x 16"
