Panasonic PT-REQ15LBUG Professional 15,000-Lumen UHD 4K Laser DLP Projector (No Lens)

Panasonic PT-REQ15LBUG 15,000-Lumen Pixel Shift UHD 4K Laser DLP Projector (No Lens, Black, TAA Compliant)

SKU PT-REQ15LBUG
Save 2% Save 2%
$70,189.00
$70,189.00 - $70,189.00
$70,189.00
$68,969.00
$68,969.00 - $68,969.00
$68,969.00

The Panasonic PT-REQ15LBUG Laser DLP Projector delivers dynamic visuals and unwavering professional reliability for demanding commercial applications. Boasting 15,000 ISO lumens, UHD 4K pixel-shift resolution, and 240 Hz projection, it is ideal for museums and entertainment venues. Connectivity includes HDMI and DisplayPort with 4K HDR support, alongside extensive LAN and RS-232 control for seamless integration. Its robust design, TAA compliance, and 20,000-hour maintenance-free operation ensure exceptional long-term performance.

Key Features
  • Brightness of 15,000 ISO Lumens
  • UHD 4K 3840 x 2400 On-Screen Resolution
  • WUXGA 1920 x 1200 Native Chip Resolution
  • 1 x DisplayPort & 2 x HDMI Inputs
  • Intel SDM-Ready Expansion Slot
  • 20,000 Hours of Maintenance Free Use
  • IP5X Certified Dust Protection
  • TAA Compliant

STEP 1

Product Selection

STEP 2

Contact Information

STEP 3

Review Information

Panasonic PT-REQ15LBUG 15,000-Lumen Pixel Shift UHD 4K Laser DLP Projector (No Lens, Black, TAA Compliant)

Enter the details below to request your custom quote in just a few minutes

Our Customers & Partners

Features

Experience dynamic visuals and professional reliability with the PT-REQ15LBUG Laser DLP Projector in black from Panasonic. Featuring a brightness of 15,000 ISO lumens, interchangeable lenses (sold separately), 4K on-screen resolution, and 240 Hz projection capability, the PT-REQ15LBUG is ideal for demanding commercial applications, like museums and small to midsize entertainment venues.

Connect devices via HDMI and DisplayPort with support for 4K HDR and HDCP 2.3. It is LAN and RS-232 controllable and compatible with many popular 3rd party functions, such as Crestron Connected, AMX DD, and PJ Link. It can be installed in any orientation to cover a wide range of uses and tricky installations. Additionally, the PT-REQ15LBUG is TAA compliant and has no NFC functionality for use in secure and government facilities.

UHD 4K via Panasonic's Quad Pixel Drive
The REQ15 Series projectors feature a Quad Pixel Drive, Panasonic's 2-axis pixel quadrupling technology, to create deep, smooth, and detailed 4K images. It supports 240 Hz projection and works with their optional real-time tracking projection-mapping system. Evolved Dynamic Contrast includes new scene-recognition circuitry to make the difference between black, white, and contrasting colors stand out dramatically and bring your content to life. Black-level settings offer precision point-based border adjustment for arbitrary screen shapes.
Effortless Workflow, Improved Expandability
The PT-REQ15LBUG responds to complex productions with expanded functions, interfaces, and options that streamline workflow. A new line of lenses improve native contrast, add powered peripheral focus, and expand the lens-shift range. An Intel SDM-specified slot integrates proprietary or third-party function boards to adapt and scale connectivity. The optimized optical engine enables projection at 15,000 lumens on 100-240VAC power for efficient installation without needing electrical construction. Other highlights include custom test patterns and preactivated upgrade kits for Geo Pro software.
Professional Reliability
The REQ15 features an optical engine and laser light source module compliant with the IP5X Dust Protected (IEC 60529) standard with all-liquid cooling, enabling up to 20,000 hours of maintenance-free projection. To prevent interruptions, Backup Input switches to a secondary signal without screen-blanking if the primary is disrupted, while a Multi Laser Drive Engine prevents brightness loss in the unlikely event of diode failure.

UPC: 885170412903

Item Includes

  • Panasonic PT-REQ15LBUG 15,000-Lumen Pixel Shift UHD 4K Laser DLP Projector (No Lens, Black, TAA Compliant)
  • Power Cord
  • Remote Control
  • 2 x AAA Battery for Remote
  • Slot Adapter
  • Limited 3-Year Manufacturer Warranty
  • Limited 3-Year Manufacturer Warranty (On Illumination Parts or 12,000 Hours, Whichever Comes First)

Not Included

  • Essential
    Lenses & Lens Adapters

Item Includes

Display System
1-Chip 0.80" DLP
Native Resolution
1920 x 1200
Maximum Brightness
15,000 Lumens (ISO)
HDR Support
Yes: HDR10/Hybrid Log Gamma
Inputs/Outputs
2x HDMI Audio, Video Input
1x DisplayPort Audio, Video Input
1x USB-A Data, LAN Input
1x USB-A Power Output
1x RJ45 (Ethernet) Control, Data, LAN Input/Output
1x DE-9/DB-9 (RS-232) Control Input
1x DE-9/DB-9 (RS-232) Control Output
1x BNC Control Input
1x BNC Control Output
1x 1/8" / 3.5 mm Mini Remote Input
1x 1/8" / 3.5 mm Mini Remote Output
1x DE-9/DB-9 Remote Input
Show More
Light Source
Laser Phosphor
Image Display
Display System
1-Chip 0.80" DLP
Native Resolution
1920 x 1200
On-Screen Resolution
Up to 3840 x 2160 via Pixel-Shift Technology
Supported Resolutions
Maximum: 3840 x 2400
Maximum Brightness
15,000 Lumens (ISO)
Aspect Ratio
Native: 16:10
Supported: 16:9
Lens
Includes Lens
No
Features
Keystone Correction
Manual to Vertical: ± 40°
Manual to Horizontal: ± 40°
HDR Support
Yes: HDR10/Hybrid Log Gamma
Multi-Input Support (PIP/PBP)
No
Ceiling Mountable
Yes
Rear Screen Projection
Yes
Built-In Speaker
No
Projection Tilt Option
Yes
Input/Output Connectors
Inputs/Outputs
2x HDMI Audio, Video Input
1x DisplayPort Audio, Video Input
1x USB-A Data, LAN Input
1x USB-A Power Output
1x RJ45 (Ethernet) Control, Data, LAN Input/Output
1x DE-9/DB-9 (RS-232) Control Input
1x DE-9/DB-9 (RS-232) Control Output
1x BNC Control Input
1x BNC Control Output
1x 1/8" / 3.5 mm Mini Remote Input
1x 1/8" / 3.5 mm Mini Remote Output
1x DE-9/DB-9 Remote Input
HDCP Support
Yes: Version 2.3
Media/Memory Card Slot
No
Number of Expansion Slots
1
Hardware
Mobile App Compatible
No
Wireless LAN / Wi-Fi
No
Bluetooth
No
General
Light Source
Laser Phosphor
Expected Lamp Life
Medium Brightness: 20,000 Hours
Low Brightness: 24,000 Hours
Security
Cable Lock Slot
Password Protection
Input Power
100 to 240 VAC, 50 / 60 Hz
Operating Conditions
32 to 113°F / 0 to 45°C at 10 to 80% Humidity
Dimensions (W x H x D)
19.6 x 8.3 x 25.5" / 498.0 x 212.0 x 648.0 mm (with Lens and Feet)
19.6 x 7.7 x 21.2" / 498.0 x 196.0 x 538.0 mm (without Lens and Feet)
Weight
59.5 lb / 27 kg
