Kramer ProScale Presentation Scaler/Switcher (9-Input)

Kramer VP-731 ProScale Presentation Scaler/Switcher (9-Input)

SKU VP-731
Save 55% Save 55%
$2,788.50
$2,788.50 - $2,788.50
$2,788.50
$1,260.89
$1,260.89 - $1,260.89
$1,260.89
  • Scales Video & Embeds Audio Signals
  • Ethernet Control/Speaker Outputs
  • Silicon Optix HQV Processing
  • Fade-thru-Black Switching Technology
  • K-IIT XL Image Insertion Technology
  • Projector Anywhere Technology
  • HDCP Compliant
  • Built-in Time Base Corrector
  • Digital Noise Reduction
  • Front-panel Lockout

STEP 1

Product Selection

STEP 2

Contact Information

STEP 3

Review Information

Kramer VP-731 ProScale Presentation Scaler/Switcher (9-Input)

Enter the details below to request your custom quote in just a few minutes

Our Customers & Partners

Features

The Kramer ProScale Presentation Scaler/Switcher (9-Input) with ethernet control and speaker outputs is used to upscale or downscale the composite, S-Video (Y/C), component video (YUV), HDMI, computer graphics video and JPEG files to a selectable computer graphics video or HDTV output resolution. This output signal is simultaneously available on an HDMI connector and 2 (15-pin) HD computer graphics video connectors.

Item Includes

  • Kramer ProScale Presentation Scaler/Switcher (9-Input)
  • Infrared Remote Control Transmitter
  • Power Cord
  • Rack Ears
  • Null-modem Adaptor
  • User Manual
  • 7-Year Warranty

Item Includes

Inputs
2 universal Y/CV, Pb/C, Pr (composite, s-Video and component)
1 Vpp/75Ω on BNC connectors
4 UXGA on a 15-pin HD (F) connector (VGA through UXGA)
2 HDMI connectors
1 USB connector
For each universal input there is a corresponding (unbalanced) audio stereo input and digital S/PDIF input on RCA connectors
For each UXGA input there is a corresponding (unbalanced) audio stereo input on a 3.5mm mini jack connector
Outputs
1 HDMI connector
2 PC (computer graphics) on 15-pin HD connectors
1 balanced stereo audio on a 5-pin terminal block
1 digital S/PDIF output on an RCA connector
Compliance With HDMI Standard
Supports HDMI and HDCP
Output Resolutions
Native HDMI, 640x480x60Hz
640x480x75Hz, 800x600x50Hz
800x600x60Hz, 800x600x75Hz
1024x768x50Hz, 1024x768x60Hz
1024x768x75Hz, 1280x768x50Hz
1280x768x60Hz, 1280x720x60Hz
1280x800x60Hz, 1280x1024x50Hz
1280x1024x60Hz, 1280x1024x75Hz
1366x768x50Hz, 1366x768x60Hz
1400x1050x50Hz, 1400x1050x60Hz
1600x1200x50Hz, 1600x1200x60Hz
1680x1050x60Hz, 1920x1080x60Hz
1920x1200x60Hz, 480px60Hz
576px60Hz, 720px50Hz
720px60Hz, 1080ix50Hz
1080ix60Hz, 1080px50Hz
1080px60Hz or custom
Controls
Front panel buttons/OSD, IR remote control, RS-232 on a 9-pin D-sub connector, Ethernet
Additional Control
Picture-In-Picture: Video-in-Graphics (or vice versa), Picture-and-Picture or Split Screen (two images side-by-side), freeze, zoom, different selectable vertical refresh rates, video and audio ProcAmp control, output image scaling and aspect ratio change, text overlay, slide show
Power Source
100-240V AC, 50/60Hz, 30VA automatic power supply
Dimensions
19 x 7 x 1.75" (48 x 18 x 4.4 cm)
Weight
6.6lb (3kg)
Packaging Info
Package Weight
7.35 lb
Box Dimensions (LxWxH)
21.4 x 13.2 x 4.3"
