Epson Pro L1060U WUXGA 3LCD Laser Projector with 4K Enhancement

Epson Pro L1060U WUXGA 3LCD Laser Projector with 4K Enhancement

SKU V11H941020
Save 52% Save 52%
$16,593.00
$16,593.00 - $16,593.00
$16,593.00
$8,039.00
$8,039.00 - $8,039.00
$8,039.00
  • White & Color Brightness of 6000 Lumens
  • WUXGA (1920 x 1200) Native Resolution
  • 1.35 to 2.2:1 Throw Ratio
  • HDBaseT, VGA, 2x HDMI Inputs

STEP 1

Product Selection

STEP 2

Contact Information

STEP 3

Review Information

Epson Pro L1060U WUXGA 3LCD Laser Projector with 4K Enhancement

Enter the details below to request your custom quote in just a few minutes

Our Customers & Partners

Features

  • Dynamic projection capabilities — advanced built-in Edge Blending, image warping and shape overlay features for a variety of applications; direct playback from USB storage media
  • Simplified installation features — full 360-degree mounting, wide lens shift, versatile connectivity; inputs including HDBaseT™ and HDMI® (HDCP 2.2)
  • Customized performance — brightness modes to maximize light source life and provide a consistent brightness level
  • Multi-projector setup software — free software controls networked projectors and gives access to warping and edge blending
  • Web- or network-based remote management — control and monitor projector status

Item Includes

  • Pro L1060U projector
  • a lens
  • power cable
  • cable cover
  • projector remote control with batteries
  • Quick Setup Sheet

Item Includes

Projection System:High-aperture Epson® 3LCD, 3-chip technologyProjection Method:Front/rear/ceiling mountDriving Method:Poly-silicon TFT Active MatrixNative Resolution:WUXGA with 4K Enhancement1 (1920 x 1200 x 2)Resolution on Screen:WUXGA with 4K Enhancement1/ 4.6 million pixels1Pixel Number in Device:2,304,000 pixels (1920 x 1200) x 3 chipsSignal Input:Maximum Display Resolution: 4096 x 2160 (resizing display)
Display Resolution: 1920 x 1200 pixelsColor Brightness - Color Light Output:6,000 lumens2White Brightness - White Light Output:6,000 lumens2Aspect Ratio:Supports 4:3, 16:9, 16:10Brightness Uniformity:85%Pixel Arrangement:Cross stripeContrast Ratio:2,500,000:1 (Dynamic Contrast: On)Color Reproduction:Up to 1.07 billion colorsLight Source Life:20,000 hours (Normal)3Illumination Technology:Laser Phosphor

General:

Operating Temperature:32 ? to 113 ? F (0 ? to 45 ? C)Weight:34.4 lb without lensSecurity:Security cable hole, Kensington lock provision

Projection Lens:

Type:Powered shift/focus/zoom (ELPLM08 Lens)F-number:1.7 – 2.3 (ELPLM08 Lens)Focal Length:24.0 mm – 38.2 mm (ELPLM08 Lens)Zoom Ratio:Optical zoom 1 – 1.6x (ELPLM08 Lens)Throw Ratio Range:1.44 – 2.33 (ELPLM08 Lens)Lens Shift:Vertical: ±67 percent; Horizontal: ±30 percent (ELPLM08 Lens)

Projector Details:

Input Signal:Input Video Signal (HDMI, DVI-D and HDBaseT ports) 480i/480p/576i/576p/720p/1080i/1080p/3840 x 2160/ 4096 x 2160Interfaces:
  • DVI-D x 1
  • HDMI (HDCP 2.2) x 1
  • HDBaseT x 1
  • 5-BNC, VGA x 1
  • Audio in: Mini Stereo x 3
  • Variable audio out: Mini Stereo x 1
  • USB connector Type B x 1: For service only
  • USB connector Type A x 1: For wireless LAN, service, content playback
  • Monitor out: Mini D-sub 15-pin x 1
  • Serial: RS-232c x 1
  • Remote Stereo Mini x 1
  • Wired LAN: RJ45
Fan Noise:34 dB (Normal Mode); 32 dB (Medium Mode) 30 dB (Quiet Mode)

Projector Dimensions:

Including feet - with standard lens:21.5" x 7.4" x 19.1" (545 x 189 x 484 mm)

Remote Control:

Features:Power, source search selection, lens shift, zoom, focus, test pattern selection, A/V Mute, freeze, user ID, auto, aspect, color mode, number, page up and down, E-zoom, volume, menu, enter, esc and pointer functionsOperating Distance:98 ftOperating Angle:
  • Right/left: Front: ± 60 degrees; Rear: ± 30 degrees
  • Upper/lower: Front: + 30 to - 20 degrees; Rear: +50 to + 10 degrees

Power:

Power Supply Voltage:100 – 240 V ±10%, 50/60 Hz ACPower Consumption:361 W (Normal Mode), 263 W (Extended Mode), 2W (Network Standby), 0.5 W (Energy Saving)
