Item Includes
Image Sensor
1/2.8"-Type
Focal Length
3 to 8.5mm
Field of View
Horizontal: 104 to 34°
Vertical: 76 to 26°
Built-In Microphone
No
Power I/O
1x RJ45
Imaging
Number of Lenses
1
Image Sensor
1/2.8"-Type CMOS
Effective Sensor Resolution
5 Megapixel
IR Cut Filter
Yes
Day/Night
Yes
DORI Coverage
With 3 to 8.5mm Lens:
Detect: 197 to 558' / 60.0 to 170.1 m
Observe: 79.0 to 220.0' / 24.1 to 67.1 m
Recognize: 39.0 to 112.0' / 11.9 to 34.1 m
Identify: 20 to 56' / 6.1 to 17.1 m
Exposure Control
Shutter Speed
1/30500 to 2 Seconds
Signal-to-Noise Ratio
55 dB
Minimum Illumination
0.1 Lux (Color)
0 Lux (Black and White)
Lens
Focal Length
3 to 8.5mm
Max Optical Zoom
2.8x
Field of View
Horizontal: 104 to 34°
Vertical: 76 to 26°
Maximum Aperture
f/1.38 to 2.58
Video
Supported Protocols
Video Streaming
FTP/Zero Configuration/Bonjour/ICMP/SMTP/SNMP v1/v2c/v3 (MIB-II)/LLDP/ONVIF Profile T/SFTP/ARP/HTTP/MQTT/SRTP/mDNS/CDP/SSL/TLS/DDNS/CIFS/SMB/SSH/NTP/IGMP/DNS/UDP/QoS Layer 3 DiffServ/syslog/DHCP/TCP/ONVIF Profile G/ONVIF Profile M/IPv4/v6/RTP/UPnP/USGv6/RTCP/RTSP/ONVIF Profile S
Max IP Streaming
H.264, H.265, MJPEG via RJ45
2560 x 1440 up to 30.00 fps
Multi-View Streaming
Yes
Control
Camera Angle Adjustment
Horizontal: -190 to 190°
Vertical: -50 to 80°
Rotation: -95 to 95°
Networking
Security
Digest Authentication, HTTPS, IEEE 802.1X, Password Protection
Interface
Media/Memory Card Slot
Single Slot: microSD/microSDHC/microSDXC
Audio I/O
1x 1/8" / 3.5 mm TS Mono Mic/Line Input
Other I/O
1x RJ45
1x Block 4-Pin Input/Output
1- or 2-Way Audio
One-Way
Audio Formats
AAC-LC, G.711, G.726, LPCM, Opus
Built-In Microphone
No
Memory
2 GB RAM / 8000 MB Flash
External Storage Options
Cloud, NAS
System Integration
Analytics
Abandoned Object, Audio Detection, License Plate Recognition, Motion Detection, Object Counting, Object Detection, Object Removal, People Counting, People Detection, Privacy Guard, Scene Change Detection, Sound Classification, Vehicle Detection, Virtual-Line Crossing Detection
Built-In Installation Aids
Level Grid, Pixel Counter, Remote Focus, Remote Zoom, Straighten Image
Sensors & Alarms
Event Trigger
Yes
Event Action
Recording, Notification, Alarm
Alarm I/O
1 / 1
Power
PoE Support
Yes: PoE+ 802.3at, PoE 802.3af
Power I/O
1x RJ45
Power Consumption
PoE: 4.7 W with IR Off
PoE: 12.6 W with Heater, IR On
Environmental
Operating Conditions
-40 to 122°F / -40 to 50°C at 10 to 100% Humidity
Storage Conditions
-40 to 149°F / -40 to 65°C at 5 to 95% Humidity
Impact Resistance
Impact-Resistant (IK10)
Environmental Resistance
Dust/Weather/Water-Resistant (IP66)
Startup Temperature
-22°F / -30°C
General
Materials
Plastic, Polycarbonate
Certifications
CAN/CSA, CE, EAC, EN, EU, FCC, ICES, IEC, IEC/EN, IEC/EN/UL, NEMA, RCM, REACH, RoHS, TAA, UKCA, UL, VCCI, cUL
Illumination
850 nm IR LEDs up to 131.2' / 40 m
Supported Languages
Czech
Dutch
English
Finnish
French
German
Italian
Japanese
Korean
Polish
Portuguese
Russian
Simplified Chinese
Spanish
Swedish
Thai
Traditional Chinese
Turkish
Vietnamese
Dimensions (W x H x D)
7.2 x 6.1 x 5.9" / 183 x 156 x 149 mm
Weight
1.9 lb / 850 g (Body Only)
Packaging Info
Package Weight
2.645 lb
Box Dimensions (LxWxH)
7.8 x 7.5 x 7.1"
